120TAC20X+L
Angular Contact Ball Bearings
New Designations :
120TAC20X+L
Main demensions :
120 × 180 ×
72
Bore Dia × Outside Dia × Width Dia (mm)
M :
5.5 kg
Weight
ID :
120 mm
Inside diameter(I.D.)
OD :
180 mm
Outside diameter(O.D.)
T(B) :
72 mm
Thickness(W.D.)
C :
106 kN
Radial dynamic load rating
C0 :
375 kN
Radial static load rating
Grease rpm :
3000 r/min
Reference speed
Oil rpm :
3400 r/min
Limiting speed
Interchangeable :
NSK
Category :
Angular Contact Ball Bearings
Angular Contact Ball Bearings 120TAC20X+L, 5.5 kg Bearing mass, (120*180*72 mm), 120 mm d (Bore: diameter of the inner ring), 180 mm D (Outside: diameter of the outer cylindrical surface of the outer ring), 72 mm B (Width: nominal width of the bearing), 106000 N radial dynamic load capacity (Dyn. Cr), 375000 N radial static load capacity (Stat. Cor), 3000 r/min Maximum RPM (Speed in grease), 3400 r/min Maximum RPM (Speed in oil)
- Min. Order: 1 Piece/(120TAC20X+L, 120 = ID, 180 = OD, 72 = B, 5.5 kg) or according to different suppliers
- Price: Different brands, different quality, different 120TAC20X+L prices, different suppliers and different quality determine different prices, you can ask the supplier in detail for the price according to your own needs.
- Precision Rating: DIN: P2~P0; ANSI: ABEC9~ABEC1; JIS: JIS~JIS0; ISO: CLASS2~NORMAL CLASS; GB/T30794 B~G
- Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp
