22218KM C3 W33 RCC

Bore
90 mm
Outer
160 mm
Width
40 mm
Wight
3.2 kg
Spherical Roller Bearings
Self-aligning, capable of withstanding heavy loads and impacts, suitable for applications such as mining and metallurgy where shaft deflection or installation errors are present.

Main technical Specifications

New Designations :
22218KM C3 W33 RCC
Main demensions :
90 × 160 × 40
Bore Dia × Outside Dia × Width Dia (mm)
M :
3.2 kg
Weight
HS Code :
8482300000
Bearing customs code
ID :
90 mm
Inside diameter(I.D.)
OD :
160 mm
Outside diameter(O.D.)
T(B) :
40 mm
Thickness(W.D.)
Category :
Spherical Roller Bearings

Detailed parameters and installation dimensions:

Part Number: 22218KM C3 W33 RCC China
Technical description (KM C3 W33): K=Tapered Bore, Taper 1:12. M=Machined Brass Cage, Located On The Rolling Elements. C3=Internal Clearance Larger Than Normal. W33=Lubrication Groove And 3 Holes In Bearing Outer Ring.
Bearing Type: Double row spherical roller bearings
Bearing Size (metric): Bore Dia. (d): 90,00 mm X Outer dia. (D): 160,00 mm X Width (B): 40,00 mm or Size: 90,00 mm * 160,00 mm * 40,00 mm
Original Equipment Manufacture(OEM NO.): 22218KM C3 W33
Bore: K (Tapered Bore (Taper 1:12), Standard for Most Types)
Lubrication designation: W33 (Lubrication Groove and Three Holes)
Seals Type: No Seal
Cage Design: M (Brass Cage)
Radial internal clearance: C3 Internal clearance (Higher than Normal)
Precision Rating: Standard class precision
Thermal Stability: No Thermal Stability - Temperatures up to 120°C
Vibrating screen special performance: No

NOTE: All other trademarks are the property of their respective owners, used for the purpose of compatibility description and product identification only. Tradebearings is not affiliated with, endorsed by, or sponsored by the holders of these trademarks.

22218KM C3 W33 RCC refers to a type of Spherical Roller Bearings, with dimensions 90 mm (Bore) x 160 mm (OD) x 40 mm (Width), designed for Self-aligning, high load-bearing capacity, impact resistant, and adaptable to heavy loads, primarily used in Gearboxes, drive shafts, conveying equipment, general machinery, for applications Provides stable and reliable support for the rotating shaft under harsh, heavy-load conditions and in misaligned working conditions. It weight approximately 3.2 kilogram.

  • Min. Order: 1 Piece/(22218KM C3 W33 RCC, 90 = ID, 160 = OD, 40 = B, 3.2 kg) or according to different suppliers
  • Price: Different brands, different quality, different 22218KM C3 W33 RCC prices, different suppliers and different quality determine different prices, you can ask the supplier in detail for the price according to your own needs.
  • Precision Rating: DIN: P2~P0; ANSI: ABEC9~ABEC1; JIS: JIS~JIS0; ISO: CLASS2~NORMAL CLASS; GB/T30794 B~G
  • Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp

quote for the NSK R166 bearing

To whom it may concern, I need a quote for the NSK R166 of quantity 14. Regards,

✨What are the Benefits of choosing 22218KM C3 W33 RCC bearings?

  • Self-aligning: Allows for significant angular errors or shaft deflection between the shaft and bearing housing, effectively compensating for installation errors and shaft deformation.
  • High load capacity: Featuring a double-row roller structure, it boasts extremely high radial load capacity while also withstanding certain bidirectional axial loads.
  • Adaptable to vibration applications: Performs excellently under impact and vibration loads, exhibiting good durability.
  • Easy installation: Models with tapered bores are typically available, allowing for convenient installation at any position on different optical shafts using adapter sleeves or withdrawal sleeves.
  • The 22218KM C3 W33 RCC Spherical Roller Bearings adopts a Self-aligning, high load-bearing capacity, impact resistant, and adaptable to heavy loads design, with dimensions an inner diameter of 90 mm, an outer diameter of 160 mm, a width of 40 mm, ensure the equipment operates more stably for applications Provides stable and reliable support for the rotating shaft under harsh, heavy-load conditions and in misaligned working conditions.

🏭 What are the applications of the 22218KM C3 W33 RCC bearing?

  • Mining/Metallurgy/Cement: Used in crushers and vibrating screens. Impact resistant, withstands extreme heavy loads, and adaptable to harsh environments.
  • Paper/Steel: Used in rolling mills and roller conveyors. Automatic self-aligning compensation effectively addresses shaft deflection or misalignment.
  • Industrial Transmission: Used in speed reducers and fans. Smooth operation, long service life, and withstands complex composite loads.
