2231CDE4

Bore
60 mm
Outer
130 mm
Width
46 mm
Wight
2.8 kg
Spherical Roller Bearings
Self-aligning, capable of withstanding heavy loads and impacts, suitable for applications such as mining and metallurgy where shaft deflection or installation errors are present.

Main technical Specifications

New Designations :
2231CDE4
Main demensions :
60 × 130 × 46
Bore Dia × Outside Dia × Width Dia (mm)
M :
2.8 kg
Weight
HS Code :
8482300000
Bearing customs code
ID :
60 mm
Inside diameter(I.D.)
OD :
130 mm
Outside diameter(O.D.)
T(B) :
46 mm
Thickness(W.D.)
Category :
Spherical Roller Bearings

Detailed parameters and installation dimensions:

Part Number: 2231CD E4 NSK
Technical description (CD E4): CD=(CC-SKF)=Spherical Roller Bearing, Two-Piece Pressed Steel Cage With Guide Ring. E4=W33 (SKF)=Lubrication Groove And Three Holes In Bearing Outer Ring.
Bearing Type: Double row spherical roller bearings
Bearing Size (metric): Bore Dia. (d): 60 mm X Outer dia. (D): 130 mm X Width (B): 46 mm or Size: 60 mm * 130 mm * 46 mm
Original Equipment Manufacture(OEM NO.): 2231CD E4
Bore: C (Cylindrical Bore)
Lubrication designation: W33 (Lubrication Groove and Three Holes)
Seals Type: No Seal
Cage Design: S (Steel or Standard Cage)
Radial internal clearance: Cn (Normal Internal clearance)
Precision Rating: Standard class precision
Thermal Stability: No Thermal Stability - Temperatures up to 120°C
Vibrating screen special performance: No

NOTE: All other trademarks are the property of their respective owners, used for the purpose of compatibility description and product identification only. Tradebearings is not affiliated with, endorsed by, or sponsored by the holders of these trademarks.

2231CDE4 refers to a type of Spherical Roller Bearings, with dimensions 60 mm (Bore) x 130 mm (OD) x 46 mm (Width), designed for Self-aligning, extremely strong load-bearing capacity, and impact resistant, primarily used in Heavy-duty speed reducers, low-speed rolling mills, and medium-sized mining equipment, for applications Provides stable and reliable support for the rotating shaft under harsh, heavy-load conditions and in misaligned working conditions. It weight approximately 2.8 kilogram.

  • Min. Order: 1 Piece/(2231CDE4, 60 = ID, 130 = OD, 46 = B, 2.8 kg) or according to different suppliers
  • Price: Different brands, different quality, different 2231CDE4 prices, different suppliers and different quality determine different prices, you can ask the supplier in detail for the price according to your own needs.
  • Precision Rating: DIN: P2~P0; ANSI: ABEC9~ABEC1; JIS: JIS~JIS0; ISO: CLASS2~NORMAL CLASS; GB/T30794 B~G
  • Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp

E2379213-SKF SPEEDY SLEEVES

hi, Please quote if you can supply below. SKF SPEEDY SLEEVES FOR SHAFT REPAIR KIT STOCK NO- 99313 (SHAFT DIA RANGE --79.81 TO 80.01 MM) NOMINAL SHAFT DIA -- 80 MM

✨What are the Benefits of choosing 2231CDE4 bearings?

  • Extreme Heavy-Duty Capacity: Highest rated load in its class, approximately 50% higher than the 222 series, designed for extreme heavy loads and harsh conditions.
  • Superior Durability: Withstands extremely high bidirectional axial and radial impacts; its internal design is also exceptionally vibration-resistant, ensuring stable operation.
  • Self-Alignment Compensation: Effectively compensates for shaft deflection or installation misalignment (typically allowing 1-2°) without affecting bearing life.
  • Robust Cage: Standard one-piece precision brass cage provides excellent guidance and exceptional reliability and durability in harsh environments.
  • The 2231CDE4 Spherical Roller Bearings adopts a Self-aligning, extremely strong load-bearing capacity, and impact resistant design, with dimensions an inner diameter of 60 mm, an outer diameter of 130 mm, a width of 46 mm, ensure the equipment operates more stably for applications Provides stable and reliable support for the rotating shaft under harsh, heavy-load conditions and in misaligned working conditions.

🏭 What are the applications of the 2231CDE4 bearing?

  • Mining/Metallurgy/Cement: Used in crushers and vibrating screens. Impact resistant, withstands extreme heavy loads, and adaptable to harsh environments.
  • Paper/Steel: Used in rolling mills and roller conveyors. Automatic self-aligning compensation effectively addresses shaft deflection or misalignment.
  • Industrial Transmission: Used in speed reducers and fans. Smooth operation, long service life, and withstands complex composite loads.
