51120
Thrust Ball Bearings
1/2
Main technical Specifications
New Designations :
51120
Main demensions :
100 × 135 ×
25
Bore Dia × Outside Dia × Width Dia (mm)
M :
0.96 kg
Weight
ID :
100 mm
Inside diameter(I.D.)
OD :
135 mm
Outside diameter(O.D.)
T(B) :
25 mm
Thickness(W.D.)
Cr :
86 kN
Radial dynamic load rating
C0r :
268 kN
Radial static load rating
Grease rpm :
1700 r/min
Reference speed
Oil rpm :
2600 r/min
Limiting speed
Interchangeable :
NSK
Category :
Thrust Ball Bearings
Detailed parameters and installation dimensions:
| Part Code | 51120 | |
|---|---|---|
| Bearing Type | Thrust ball bearing, single direction | |
| Inside Diameter (d) | 100mm | |
| Outside Diameter (D) | 135mm | |
| Thickness (T) | 25mm | |
| D1 | 102mm | |
| Da max | 114mm | |
| d1 | 135mm | |
| da min | 121mm | |
| ra max | 1mm | |
| rmin | 1mm | |
| m | 0.992kg | Mass |
| Ca | 85000N | Axial Dynamic Load Capacity |
| C0a | 270000N | Axial Static Load Capacity |
| Cua | 11300N | Fatigue Load Capacity For Axial |
| nG | 35001/min | Limiting speed |
| nϑr | 31001/min | Reference speed |
| A | 0.36 | Minimum load coefficient |
Thrust Ball Bearings 51120, 0.96 kg Bearing mass, (100*135*25 mm), 100 mm d (Bore: diameter of the inner ring), 135 mm D (Outside: diameter of the outer cylindrical surface of the outer ring), 25 mm B (Width: nominal width of the bearing), 86000 N radial dynamic load capacity (Dyn. Cr), 268000 N radial static load capacity (Stat. Cor), 1700 r/min Maximum RPM (Speed in grease), 2600 r/min Maximum RPM (Speed in oil)
- Min. Order: 1 Piece/(51120, 100 = ID, 135 = OD, 25 = B, 0.96 kg) or according to different suppliers
- Price: Different brands, different quality, different 51120 prices, different suppliers and different quality determine different prices, you can ask the supplier in detail for the price according to your own needs.
- Precision Rating: DIN: P2~P0; ANSI: ABEC9~ABEC1; JIS: JIS~JIS0; ISO: CLASS2~NORMAL CLASS; GB/T30794 B~G
- Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp
Specifications From Tradebearings:
| Attributes | Values |
| Bearing Part Code | 51120 Bearing |
| Units | mm |
| Bearing Type | with grooved raceway(s) are available |
| Inside (d) | 100mm |
| Outside (D) | 135mm |
| rs min | 1 |
| C0r - Radial Stat. | 248000 |
| Cr - Radial Dyn. | 79300 |
| Maximum Reference Speed (Grease) | 2 |
| Maximum Limiting Speed (Oil) | 2 |
| Height (H) | 25mm |
| Outer Dia. Pilot (D1) | 135mm |
| Bore Diameter Clearance (d1) | 102mm |
| Bearing Mass | 990 |
| Bearing Material | 52100 chrome steel, or equivalent. |
Data Transfering...
Wafangdian AA Bearing Trade Co.,Ltd
Email: [email protected] Tel: 86-159-06428604 2021-12-0551120 Thrust Ball Bearing 100x135x25mm;
Bore Diameter (id) = 100mm; Outside Diameter (OD) = 135mm; High (H) = 25mm; Dynamic Load Of Radial (Cr) = 85.2 kN; Static Load Of Radial (C0r) = 290 kN; Pu = 10 kN; Minimum load factor A = 0.44; Reference Speed For Grease = 2400 rpm; Maximum Speed RPM = 3200 rpm; Bearing Mass = 0.97 kg; d1 = 135mm; D1 = 102mm; r1r2 min = 1mm; da min = 121mm; Da max = 114mm; ra max = 1mm
