52330X bearing, Thrust Ball Bearings 150x250x140, 30.3 KG

🔍

1/2

Main technical Specifications

New Designations :

52330X

Main demensions :

150 × 250 × 140

Bore Dia × Outside Dia × Width Dia (mm)

M :

30.3 kg

Weight

ID :

150 mm

Inside diameter(I.D.)

OD :

250 mm

Outside diameter(O.D.)

T(B) :

140 mm

Thickness(W.D.)

Cr :

380 kN

Radial dynamic load rating

C0r :

1200 kN

Radial static load rating

Grease rpm :

630 r/min

Reference speed

Oil rpm :

950 r/min

Limiting speed

Interchangeable :

NSK

Category :

Thrust Ball Bearings

Thrust Ball Bearings 52330X, 30.3 kg Bearing mass, (150*250*140 mm), 150 mm d (Bore: diameter of the inner ring), 250 mm D (Outside: diameter of the outer cylindrical surface of the outer ring), 140 mm B (Width: nominal width of the bearing), 380000 N radial dynamic load capacity (Dyn. Cr), 1200000 N radial static load capacity (Stat. Cor), 630 r/min Maximum RPM (Speed in grease), 950 r/min Maximum RPM (Speed in oil)

Min. Order: 1 Piece/(52330X, 150 = ID, 250 = OD, 140 = B, 30.3 kg) or according to different suppliers
Price: Different brands, different quality, different 52330X prices, different suppliers and different quality determine different prices, you can ask the supplier in detail for the price according to your own needs.
Precision Rating: DIN: P2~P0; ANSI: ABEC9~ABEC1; JIS: JIS~JIS0; ISO: CLASS2~NORMAL CLASS; GB/T30794 B~G
Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp
