6030-C3
Main technical Specifications
Detailed parameters and installation dimensions:
| Part Number | 6030-C3 |
| Series | 60 |
| Bearing Mass - m | 4.32 kg | 9.524 lb |
| Reference speed - nB | 3818 min–1 |
| Limiting speed - nG | 3913 min–1 |
| Reference From | FAG 6030-C3 |
| Dimension Inside - d φ (mm) | 150 |
| Dimension Outside - D Φ (mm) | 225 |
| Dimension Width - B (mm) | 35 |
| Bore Type | Z = Cylindrical bore |
| Bearing Type | Deep groove ball bearings open design, self-retaining |
| Dimension - r(min.) | 2.1 mm | 0.083 inch |
| Dimension - D1 | 201.42 mm | 7.930 inch |
| Dimension - d1 | 174.36 mm | 6.865 inch |
| Rows NO. | one |
| Mounting dimensions - da(min.) | 160.2 mm | 6.307 inch |
| Seal | Open |
| Mounting dimensions - Da(max.) | 214.8 mm | 8.457 inch |
| Mounting dimensions - ra(max.) | 2.1 mm | 0.083 inch |
| Cage | JN = Stamping steel cage |
| RIC | C3 |
| Manufacturer Part Code | 6030.C3 |
| Radial Dynamic Capacity - Cr | 130901 N | 29426 lbf |
| Radial static Capacity - C0r | 123905 N | 27853 lbf |
| Heat stabilization | S0 = (up to 150 °C) |
| Lubricant | Without |
| Dimension Inside - d φ (inch) | 5.905 |
| Dimension Outside - D Φ (inch) | 8.858 |
| Dimension Width - B (inch) | 1.378 |
| Temperature - T(min) | -30°C |
| Temperature - T(max) | 150°C |
| Equivalent | 6030.C3 |
| Radial Fatigue Capacity - Cur | 5578 N | 1253 lbf |
| Coefficient - F0 | 16 |
| Ring Material | GCr15SiMn |
NOTE: All other trademarks are the property of their respective owners, used for the purpose of compatibility description and product identification only. Tradebearings is not affiliated with, endorsed by, or sponsored by the holders of these trademarks.
6030-C3 refers to a type of 60 Deep groove ball bearings open design, self-retaining, with dimensions 150 mm (Bore) x 225 mm (OD) x 35 mm (Width), designed for Simple structure and highly versatile, primarily used in Electric motors, automobiles, general equipment, Its normal operating speed can reach: the grease speed ratings: 3818 rpm, oil speed ratings: 3913 rpm, featuring one (row) construction, JN = Stamping steel cage retainer to ensure extended service life, advanced Open, PN (precision) for applications The vast majority of motors, transmission systems, and general-purpose machinery (general-purpose, economical, and efficient). it's built to handle significant loads (dynamic radial: 130901 N, static radial: 123905 N, ), It weight approximately 4.32 kilogram.
- Min. Order: 1 Piece/(6030-C3, 150 = ID, 225 = OD, 35 = B, 4.32 kg) or according to different suppliers
- Price: Different brands, different quality, different 6030-C3 prices, different suppliers and different quality determine different prices, you can ask the supplier in detail for the price according to your own needs.
- Precision Rating: DIN: P2~P0; ANSI: ABEC9~ABEC1; JIS: JIS~JIS0; ISO: CLASS2~NORMAL CLASS; GB/T30794 B~G
- Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp
Specifications From Tradebearings:
Manufacturer Part Code: 6030-C3;
Dimension Inside - id φ: 150 mm;
Dimension Outside - OD Φ: 225 mm;
Dimension Width - B: 1.378 inch;
Type Of Bore: Cylindrical Bore;
Type of Closure: Open;
Snap Ring Included: No;
Radial Internal Play: C3;
Operating Temp Max.: 120° C;
Dyn. Load Rating: 29607.3377197681 lb;
Stat. Load Rating: 27988.7133341771 lb;
Running Accuracy Class: ABEC 1;
Material of Bearing: Steel;
Material of Cage: Steel;
Width Of Inner Ring: 1.378 inch;
Width Of Outer Ring: 1.378 inch;
Fillet Radius(ra): 0.0827 inch;
Bearing Series: 6000;
Bearing Mass (m): 8.995 lbs;
Data Transfering...
Wafangdian AA Bearing Trade Co.,Ltd
Email: [email protected] Tel: 86-159-06428604 2021-11-216030-C3 Deep Groove Ball Bearing, 150 mm = Bore (d), 225 mm = D, 35 mm = B, 131000 N = Load Capacity; Brand: Interchangeable From FAG 6030-C3 or OEM;
Material Of Bearing = Steel;
Seal Close Type = Open;
Material Of Cage = Sheet Steel;
Max speed = 3950 rpm;
Bearing Series = Extra Light Series;
Operating Temperature Range = -30 to 150 °C;
Bore Dia. (d) = 150 mm;
Outside Dia. (D) = 225 mm;
Number of Rows = 1;
Width (B) = 35 mm;
Load Rating = 131000 N
