73619АМН
Main technical Specifications
NOTE: All other trademarks are the property of their respective owners, used for the purpose of compatibility description and product identification only. Tradebearings is not affiliated with, endorsed by, or sponsored by the holders of these trademarks.
73619АМН refers to a type of Spherical Roller Bearings, with dimensions 95 mm (Bore) x 215 mm (OD) x 73 mm (Width), designed for Self-aligning, high load-bearing capacity, and impact resistant, primarily used in Metallurgy, Mining and Building Materials Industries, for applications Provides stable and reliable support for the rotating shaft under harsh, heavy-load conditions. It weight approximately 13.75 kilogram.
- Min. Order: 1 Piece/(73619АМН, 95 = ID, 215 = OD, 73 = B, 13.75 kg) or according to different suppliers
- Price: Different brands, different quality, different 73619АМН prices, different suppliers and different quality determine different prices, you can ask the supplier in detail for the price according to your own needs.
- Precision Rating: DIN: P2~P0; ANSI: ABEC9~ABEC1; JIS: JIS~JIS0; ISO: CLASS2~NORMAL CLASS; GB/T30794 B~G
- Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp
Data Transfering...
✨What are the Benefits of choosing 73619АМН bearings?
🏭 What are the applications of the 73619АМН bearing?
📐 How should choose the right model for a Spherical Roller Bearings?
1. Verify load and direction: Confirm that the bearing can withstand high radial loads and bidirectional axial loads. Generally, the axial load should not exceed 15-20% of the radial load, and in extreme cases, it should not exceed 35%, otherwise uneven stress may occur.
2. Confirm dimensions and tolerances: Determine the bore diameter, outer diameter, and width based on the installation space, and select the tolerance grade (e.g., PN grade) according to standards such as DIN 635-2 or ISO 15.
3. Select internal design: Select the cage type (e.g., CA type brass cage) and lubrication features (e.g., W33 outer ring oil groove and oil hole) according to the application.
4. Consider self-aligning capability: Check its maximum permissible self-aligning angle (usually 1° to 2°) to ensure it can compensate for installation errors or shaft deflection.
🛠️ What is the mounting procedure for 73619АМН bearings?
1. Preparation and Cleaning: Before installation, be sure to clean the shaft and bearing housing, and check all mating surfaces for burrs or damage.
2. Heated Installation (Recommended): For interference fits, use an induction heater to evenly heat the bearing to 80-100°C, then quickly push it onto the shaft, pressing it against the shaft shoulder. Do not exceed 120°C to avoid altering the material structure.
3. Cold Installation (Alternative): If heating is not possible, use an installation sleeve and press to apply pressure only to the inner ring to press the bearing into place.
4. Securing and Lubrication: Tighten the bearing with a lock nut, etc., and add an appropriate amount of grease through the oil groove/hole.
5. Final Inspection: Manually rotate the shaft to confirm smooth rotation without abnormal noise, and recheck the bearing clearance.
📋 Special Note for mounting 73619АМН bearings?
Load Limitation: Avoid prolonged exposure to excessive (>20%) pure axial loads, as this may overload the single-row rollers and significantly shorten their lifespan.
Temperature Control: During heated installation, strictly adhere to the 80-100℃ range to prevent localized overheating.
Appropriate Lubrication: Double-row bearings require more grease, but the filler amount is generally 30%-60% of the bearing's internal space; excessive grease can easily cause overheating.
Installation Tools: Never directly strike the bearing's outer ring, cage, or rolling elements. Use specialized tools to apply force only to the mating rings.
Operational Monitoring: During the first run after installation, monitor temperature, vibration, and noise to ensure smooth operation.
