8311
Detailed parameters and installation dimensions:
ID: 2.165 inch, OD: 4.724 inch, T/B: 2.283 inch, Seals type: Open, Flush Ground: Yes, Rolling Element: Ball Bearing, Single Row
Part Number: 8311 MRC/Marlin Rockwell
Bearing Type: Angular Contact Ball Bearings, Double Row
Bearing Size(metric): Inner dia. (d): 55 mm X Outer dia. (D): 120 mm X Width (B): 58 mm or Size: 55 mm * 120 mm * 58 mm
Original Equipment Manufacture(OEM NO.): 8311
Bore: C (Cylindrical Bore)
Seals Type: No Seal
Cage Design: M (Brass Cage)
Radial internal clearance:Cn Normal Internal
Precision Rating: 77 - ABEC.3 Tolerances
Type of lubrication: Standard class lubrication
Thermal Stability: No Thermal Stability - Temperatures up to 120°C
Split Innering / Outerring: Standard
NOTE: All other trademarks are the property of their respective owners, used for the purpose of compatibility description and product identification only. Tradebearings is not affiliated with, endorsed by, or sponsored by the holders of these trademarks.
8311 refers to a specialized type of Single row angular contact ball bearings, with dimensions 55 mm (Bore) x 120 mm (OD) x 58 mm (Width), designed for High speed, high precision, Low friction and low heat generation, primarily used in Precision machine tools, motors, high-speed spindles, for applications General machinery, automobiles, machine tool spindles, motors, gearbox, robots, precision instruments It weight approximately 3.195 kilogram.
Single row angular contact ball bearings (8311) features:
The raceways of the inner and outer rings of a bearing have a contact angle (typically 15°, 25°, 30°, or 40°), which allows it to withstand radial loads and axial loads in one direction simultaneously, or to withstand purely axial loads.
High-speed capability: Compact structure with spherical rolling elements, low friction, and low heat generation, making it ideal for high-speed operation.
High rotational accuracy: Typically manufactured to high grades (e.g., P5, P4, P2), ensuring extremely high rotational accuracy and smooth operation.
The 8311 bearings adopts a High speed, high precision, Low friction and low heat generation design, the equipment operates more stably .
Single row angular contact ball bearings (8311) application:
High-speed precision spindles: Spindles for high-speed machining centers, precision grinding machines, and internal grinding machines.
High-speed motors and electric spindles: High-speed variable frequency motors, dental handpieces, and small gas turbines.
Precision instruments: High-precision measuring equipment, optical rotary tables, and gyroscopes.
Robot joints: Wrist or forearm joints for lightweight industrial robots and collaborative robots.
Office automation equipment: Photosensitive drum bearings for high-speed laser printers and copiers.
- Min. Order: 1 Piece/(8311, 55 = ID, 120 = OD, 58 = B, 3.195 kg) or according to different suppliers
- Price: Different brands, different quality, different 8311 prices, different suppliers and different quality determine different prices, you can ask the supplier in detail for the price according to your own needs.
- Precision Rating: DIN: P2~P0; ANSI: ABEC9~ABEC1; JIS: JIS~JIS0; ISO: CLASS2~NORMAL CLASS; GB/T30794 B~G
- Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp
Specifications From Tradebearings:
Manufacturer Part Code: 8311 PUMPAC;
Dimension Inside - id φ: 55 mm;
Dimension Outside - OD Φ: 120 mm;
Dimension Width - B: 58 mm;
Contact Angle: 40/15 °;
Pairing Type: Back-to-back;
Type of Closure: Open;
Running Accuracy Class: ABEC 3 (ISO Class 6);
Operation Temp Rating: Maximum of +375 °F;
Radial (Dyn. load rating Cr): 40°: 101;
15°: 88.4 kN;
Radial (Stat. load rating C0r): 40°: 85;
15°: 61 kN;
Material of Bearing: Steel;
Limiting speed Max (1/min): 6300 RPM;
Material of Cage: Brass;
Surface Coating: NO;
Width Of Outer Ring: 58 mm;
Width Of Inner Ring: 58 mm;
Fillet Radius(ra): 2 mm;
Bearing Series: 8300;
Standards: ABMA;
ISO;
