EW-1/4
Detailed parameters and installation dimensions:
d: 0.250 inch, d: 6.350 mm, D: 0.656 inch, D: 16.662 mm, T: 0.250 inch, T: 6.350 mm, Weight: 0.020 lbs, Weight: 9.07 g, DYN.CAP.: 285 lbf, DYN.CAP.: 1260 N, STAT.CAP.: 101 lbf, STAT.CAP.: 450 N, SPEED LIMIT: 18000 rpm
Light cross section
Flat race
Single direction
NOTE: All other trademarks are the property of their respective owners, used for the purpose of compatibility description and product identification only. Tradebearings is not affiliated with, endorsed by, or sponsored by the holders of these trademarks.
EW-1/4 refers to a specialized type of Single direction thrust ball bearings, with dimensions 6.35 mm (Bore) x 16.662 mm (OD) x 6.35 mm (Width), designed for Pure axial load, primarily used in Home appliances, general machinery, oil speed ratings: 18000 rpm, for applications Various medium and low-speed mechanical equipment that bears moderate axial loads the Basic load can reach (dynamic radial:6350, ), It weight approximately 0.009 kilogram.
- Min. Order: 1 Piece/(EW-1/4, 6.35 = ID, 16.662 = OD, 6.35 = B, 0.009 kg) or according to different suppliers
- Price: Different brands, different quality, different EW-1/4 prices, different suppliers and different quality determine different prices, you can ask the supplier in detail for the price according to your own needs.
- Precision Rating: DIN: P2~P0; ANSI: ABEC9~ABEC1; JIS: JIS~JIS0; ISO: CLASS2~NORMAL CLASS; GB/T30794 B~G
- Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp
Specifications From Tradebearings:
Manufacturer Part Code: EW-1/4 THRUST BALL BEARING;
Dimension Inside - id φ: 0.2500 inch;
Dimension Outside - OD Φ: 0.6560 inch;
Dimension Width - B: 0.2500 inch;
Thrust Type: Single-Direction;
Outside Diameter Design: Straight;
Separable or Banded: Separable;
Race Type: Flat;
Running Accuracy Class: Not Rated;
Radial (Stat.load Cor): 450 N;
Radial (Dyn.load Cr): 1260 N;
Limiting speed (RPM): 18000 RPM;
Material of Bearing: Steel;
Bearing Series: EW;
Bearing Mass (M): 0.02 lbs
Data Transfering...
What are the Benefits of choosing EW-1/4 bearings?
Specifically designed to withstand axial forces: Designed to handle unidirectional or bidirectional axial loads, but not radial forces.
Supports high-speed operation: Point contact design results in low friction and minimal heat generation, allowing for higher speeds.
Easy to install and detach: The shaft and seat can be installed separately for convenient maintenance.
Saves axial space: Compact structure, suitable for applications with limited installation space.
The EW-1/4 bearings adopts a Pure axial load design, the equipment operates more stably , and the maximum speed can reach ( Limit Speed Ratings (oil) rpm:18000).
What are the applications of the EW-1/4 bearing?
Automotive Industry: Used in clutches, steering gears, and transmissions to ensure smooth and flexible shifting and steering.
Electric Motors and Tools: Used in vertical motors, power tools, and speed reducers to support the rotor's weight and axial load, improving rotational stability.
Light Industrial Machinery: Used in textile equipment, packaging machinery, and food processing machinery to provide stable axial support, ensuring reliable operation and a compact structure.
