IR35X42X20-IS1-XL
Needle Bearings Inner Ring
1/2
Main technical Specifications
New Designations :
IR35X42X20-IS1-XL
Old Code :
IR35X42X20-IS1
Main demensions :
35 × 42 ×
20
Bore Dia × Outside Dia × Width Dia (mm)
M :
0.065 kg
Weight
HS Code :
8482400000
Bearing customs code
ID :
35 mm
Inside diameter(I.D.)
OD :
42 mm
Outside diameter(O.D.)
T(B) :
20 mm
Thickness(W.D.)
Category :
Needle Bearings Inner Ring
Detailed parameters and installation dimensions:
Part Number: IR35X42X20-IS1-XL
Technical description (IS1-XL): IS1=One Lubrication Hole In The Inner Ring. XL=X-Life.
The equivalents designations: 4012802987980
IR35X42X20-IS1
Bearing Type: Needle Roller and Cage Assembly
Size(metric): Inner dia. (d): 35 mm X Outer dia. (D): 42 mm X Width (B): 20 mm or Size: 35 mm * 42 mm * 20 mm
Original Equipment Manufacture(OEM NO.): IR35X42X20-IS1-XL
Seals Type: No Seal
Needle Bearings Inner Ring IR35X42X20-IS1-XL, 0.065 kg Bearing mass, (35*42*20 mm), 35 mm d (Bore: diameter of the inner ring), 42 mm D (Outside: diameter of the outer cylindrical surface of the outer ring), 20 mm B (Width: nominal width of the bearing),
- Min. Order: 1 Piece/(IR35X42X20-IS1-XL, 35 = ID, 42 = OD, 20 = B, 0.065 kg) or according to different suppliers
- Price: Different brands, different quality, different IR35X42X20-IS1-XL prices, different suppliers and different quality determine different prices, you can ask the supplier in detail for the price according to your own needs.
- Precision Rating: DIN: P2~P0; ANSI: ABEC9~ABEC1; JIS: JIS~JIS0; ISO: CLASS2~NORMAL CLASS; GB/T30794 B~G
- Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp
Specifications From Tradebearings:
IR35X42X20-IS1-XL Inner Ring With Raceway, 35 mm = d, 42 mm = D, 20 mm = B, For Needle Roller Bearing, Steel; Brand: Interchangeable From INA IR35X42X20-IS1-XL or OEM;
| Bearing Series: | IR Series |
| Bore Dia. (d): | 35 mm |
| Outside Dia. (D): | 42 mm |
| The Total Width (B): | 20 mm |
| Suitable for: | Needle Roller Bearing |
| Material: | Steel |
Data Transfering...
Wafangdian AA Bearing Trade Co.,Ltd
Email: [email protected] Tel: 86-159-06428604 2022-01-03Design Units: Metric;
Bearing Item: IR35X42X20-IS1-XL;
Shaft Dia.: 35 mm;
Bore Dia (d): 35 mm;
Bore Diameter Tolerance: -0.012mm to 0;
Outer Dia: 42 mm;
Outer Diameter Tolerance: -0.009mm to 0;
Width (B): 20 mm;
Width Tolerance: -0.12mm to 0;
rmin: 0.6 mm;
Number of lubrication holes: 1;
Ring Material: Steel;
Lubrication: Lubricated;
RoHS: Compliant;
Mass (g): 63.9
