NU 1038 ECM/C4J20AA
Insulated cylindrical roller bearings
1/2
Main technical Specifications
New Designations :
NU 1038 ECM/C4J20AA
Main demensions :
190 × 290 ×
46
Bore Dia × Outside Dia × Width Dia (mm)
M :
11 kg
Weight
ID :
190 mm
Inside diameter(I.D.)
OD :
290 mm
Outside diameter(O.D.)
T(B) :
46 mm
Thickness(W.D.)
Cr :
335 kN
Radial dynamic load rating
C0r :
495 kN
Radial static load rating
Grease rpm :
1500 r/min
Reference speed
Oil rpm :
1900 r/min
Limiting speed
Category :
Insulated cylindrical roller bearings
Insulated cylindrical roller bearings NU 1038 ECM/C4J20AA, 11 kg Bearing mass, (190*290*46 mm), 190 mm d (Bore: diameter of the inner ring), 290 mm D (Outside: diameter of the outer cylindrical surface of the outer ring), 46 mm B (Width: nominal width of the bearing), 335000 N radial dynamic load capacity (Dyn. Cr), 495000 N radial static load capacity (Stat. Cor), 1500 r/min Maximum RPM (Speed in grease), 1900 r/min Maximum RPM (Speed in oil)
- Min. Order: 1 Piece/(NU 1038 ECM/C4J20AA, 190 = ID, 290 = OD, 46 = B, 11 kg) or according to different suppliers
- Price: Different brands, different quality, different NU 1038 ECM/C4J20AA prices, different suppliers and different quality determine different prices, you can ask the supplier in detail for the price according to your own needs.
- Precision Rating: DIN: P2~P0; ANSI: ABEC9~ABEC1; JIS: JIS~JIS0; ISO: CLASS2~NORMAL CLASS; GB/T30794 B~G
- Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp
