22216CC/W33
Main technical Specifications
Detailed parameters and installation dimensions:
| Part Number | 22216CC/W33 |
| Series | 222series (222..CC W33) |
| Cage | CC = stamped steel cages |
| Speed ratings (oil) - nG | 5963 rpm |
| Internal design | CC = Flangeless inner ring, guide ring centred on the inner ring, two stamped steel cages |
| Seal | Open |
| Reference From | SKF 22216CC/W33 |
| Principal Dimensions Inside - d φ (mm) | 80 |
| Inside - d φ tolerance | -0.015 mm to 0 |
| Principal Dimensions Outside - D Φ (mm) | 140 |
| Outside - D Φ tolerance | -0.018 mm to 0 |
| Principal Dimensions Width - B (mm) | 33 |
| Width - B tolerance | -0.06 mm to 0 |
| Lubrication | W33 = Annular groove and three lubrication holes in the outer ring |
| Rows NO. | 2 |
| Bore Type | Z = cylindrical bore |
| Principal Dimensions Inside - d φ (inch) | 3.150 |
| Principal Dimensions Outside - D Φ (inch) | 5.512 |
| Principal Dimensions Width - B (inch) | 1.299 |
| RIC | Normal |
| Load Direction | Combined |
| Bearing Mass - m | 2.1 kg | 4.630 lb |
| Permissible angular misalignment | 1.5 degrees |
| Dynamic Radial Capacity - Cr | 54399 lbf | 241966 N |
| Static Radial Capacity - C0r | 60501 lbf | 269108 N |
| Heat stabilization | 392 °F (200 °C) |
| Temperature - T(min) | -30 °C |
| Temperature - T(max) | +200 °C |
| Dimension - d2 | 94.7 mm | 3.728 inch |
| Units | Metric |
| Roller bearing type | Spherical |
| Dimension - D1 | 124 mm | 4.882 inch |
| Bearing Type | Spherical roller bearings, double row |
| Manufacturer Part Code | 22216 CC/W33 |
| Ring material | GCr15SiMn |
| Dimension - b | 6 mm | 0.236 inch |
| Roller material | GCr15SiMn |
| Dimension - K | 3 mm | 0.118 inch |
| Dimension - r1,r2(min.) | 2 mm | 0.079 inch |
The equivalents & Variants model of 22216CC/W33 Spherical Roller Bearings:
SKF 22216CC , NTN 22216BD1 , FAG 22216ES·TVPB , NSK 22216HE4 , NACHI 22216EW33 , TORRINGTON 22216VCFW33 , KOYO 22216RHW33 ,
NOTE: All other trademarks are the property of their respective owners, used for the purpose of compatibility description and product identification only. Tradebearings is not affiliated with, endorsed by, or sponsored by the holders of these trademarks.
22216CC/W33 refers to a type of 222 Spherical roller bearings, double row, with dimensions 80 mm (Bore) x 140 mm (OD) x 33 mm (Width), designed for Self-aligning, high load-bearing capacity, impact resistant, and adaptable to heavy loads, primarily used in Gearboxes, drive shafts, conveying equipment, general machinery, Its normal operating speed can reach: oil speed ratings: 5963 rpm, featuring 2 (row) construction, CC = stamped steel cages retainer to ensure extended service life, advanced Open, for applications Provides stable and reliable support for the rotating shaft under harsh, heavy-load conditions and in misaligned working conditions.. it's built to handle significant loads (dynamic radial: 242905 N, static radial: 269520 N, ), It weight approximately 2.1 kilogram.
- Min. Order: 1 Piece/(22216CC/W33, 80 = ID, 140 = OD, 33 = B, 2.1 kg) or according to different suppliers
- Price: Different brands, different quality, different 22216CC/W33 prices, different suppliers and different quality determine different prices, you can ask the supplier in detail for the price according to your own needs.
- Precision Rating: DIN: P2~P0; ANSI: ABEC9~ABEC1; JIS: JIS~JIS0; ISO: CLASS2~NORMAL CLASS; GB/T30794 B~G
- Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp
