HK5528
Needle Roller Bearings
1/2
Main technical Specifications
New Designations :
HK5528
Main demensions :
55 × 63 ×
28
Bore Dia × Outside Dia × Width Dia (mm)
M :
0.105 kg
Weight
HS Code :
8482400000
Bearing customs code
ID :
55 mm
Inside diameter(I.D.)
OD :
63 mm
Outside diameter(O.D.)
T(B) :
28 mm
Thickness(W.D.)
Cr :
39.09 kN
Radial dynamic load rating
C0r :
98 kN
Radial static load rating
Oil rpm :
4600 r/min
Limiting speed
Category :
Needle Roller Bearings
Detailed parameters and installation dimensions:
Part Number: HK5528
The equivalents designations: 7316570891164
Bearing Type: Needle Roller and Cage Assembly
Size(metric): Inner dia. (d): 55 mm X Outer dia. (D): 63 mm X Width (B): 28 mm or Size: 55 mm * 63 mm * 28 mm
Original Equipment Manufacture(OEM NO.): HK5528
Seals Type: No Seal
Needle Roller Bearings HK5528, 0.105 kg Bearing mass, (55*63*28 mm), 55 mm d (Bore: diameter of the inner ring), 63 mm D (Outside: diameter of the outer cylindrical surface of the outer ring), 28 mm B (Width: nominal width of the bearing), 39090 N radial dynamic load capacity (Dyn. Cr), 98000 N radial static load capacity (Stat. Cor), 4600 r/min Maximum RPM (Speed in oil)
- Min. Order: 1 Piece/(HK5528, 55 = ID, 63 = OD, 28 = B, 0.105 kg) or according to different suppliers
- Price: There are multiple professional bearing manufacturers and suppliers in China that offer HK5528. Sending an inquiry will get you quotes from multiple suppliers, allowing you to compare prices, quality, and service to find the most affordable option for HK5528 bearing.
- Inquiry ways: The right of the inquiry form, Email, skype, Whatsapp
Specifications From Tradebearings:
Reference From INA (Schaeffler) HK5528 Bearing, Needle Roller, Drawn Cup - Open Ends, 55 mm id x 63 mm OD x 28 mm B;
Manufacturer Part Code: HK5528;
Dimension Inside - id φ: 55 mm;
Dimension Outside - OD Φ: 63 mm;
Dimension Width - B: 28 mm;
Drawn Cup Type: Open Ends;
Type of Closure: Open;
NO. of Rows: One;
Operation Temp Range: Max of +140 °C;
Radial (Dyn.load Cr): 9900 lbf;
Radial (Stat.load Cor): 23200 lbf;
Material of Cage: Steel;
Limiting speed (RPM): 4700 RPM;
Running Accuracy Class: Not Rated;
Bearing Series: HK;
Hole Type: No Hole;
Standards: DIN 618-1/ISO 3245;
Bearing Mass (M): 0.28 lbs
Manufacturer Part Code: HK5528;
Dimension Inside - id φ: 55 mm;
Dimension Outside - OD Φ: 63 mm;
Dimension Width - B: 28 mm;
Drawn Cup Type: Open Ends;
Type of Closure: Open;
NO. of Rows: One;
Operation Temp Range: Max of +140 °C;
Radial (Dyn.load Cr): 9900 lbf;
Radial (Stat.load Cor): 23200 lbf;
Material of Cage: Steel;
Limiting speed (RPM): 4700 RPM;
Running Accuracy Class: Not Rated;
Bearing Series: HK;
Hole Type: No Hole;
Standards: DIN 618-1/ISO 3245;
Bearing Mass (M): 0.28 lbs
Data Transfering...
Wafangdian AA Bearing Trade Co.,Ltd
Email: [email protected] Tel: 86-159-06428604 2021-12-05HK5528 Needle Roller Bearing, Drawn Cup, 55 mm = Bore (d), 63 mm = D, 28 mm = B, 103000 N = Load Capacity; Brand: Interchangeable From INA HK5528 or OEM;
Material Of Cage = Sheet Steel;
Seal Close Type = Open;
Max speed (1/min) = 4850 rpm;
Bearing Series = HK Series;
Operating Temperature Range = -30 to 140 °C;
Bore Dia. (d) = 55 mm;
Outside Dia. (D) = 63 mm;
Number of Rows = 1;
Width (B) = 28 mm;
Load Rating = 103000 N
